Q345 Galvanized steel pipe

Product Introduction

Galvanized steel pipe is a welded steel pipe with a hot dip plating or electric galvanized layer on the surface. Galvanizing can increase the corrosion resistance of the steel pipe and extend the service life. Galvanized pipe has a wide range of uses, in addition to the pipeline pipe for water, gas, oil and other general low pressure fluids, it is also used as the oil well pipe, oil pipeline, especially in the oil field of the petroleum industry, the oil heater, the condensing cooler of the chemical coking equipment, the tube for the coal distillation and washing oil exchanger, and the pipe for the trestle pipe pile and the support frame of the mine tunnel.
Hot-dip galvanized steel pipe is widely used in construction, machinery, coal mine, chemical industry, electric power, railway vehicles, automobile industry, highways, Bridges, containers, sports facilities, agricultural machinery, petroleum machinery, prospecting machinery, greenhouse construction and other manufacturing industries.

Share:

  • Visual Inspection:Surface Inspection,Defect Detection ,Cosmetic Inspection.
  • Dimensional Inspection :Tolerance Verification,Calibration Check.
  • Chemical Analysis :Elemental Analysis ,Spectroscopic Analysis,Material Certification.
  • Mechanical Testing :Tensile Test,Yield Test,Hardness Test,Impact Test
  • NDT: UT,RT,MT,PT,ET
  • Package Inspection: Visual Inspection , Material Testing , Integrity Testing, Mark Inspection.

PRODUCT DETAILS

Tisco Hongcheng Tech Co.,Ltd

Uter Diameter1/2”~16” 20~406mm
Thickness0.8~2.75mm
LengthNormal 5.8m, 6m ,random length can be customized
Zinc Coating40~275g/㎡
ToleranceOD:+/-0.5mm
WT: +/-0.05mm
Length: +/-20mm
StraightnessAs Per Standard
CertificateISO 9001,IS014001,ISO45001,ISO50001,CE,LR,ICC,SGS.BV etc
Surface TreatmentZinc plated ,Passivation, Marking,Embossing
Pipe EndPlain end / Blunt end / Screwed and socked & protected by plastic caps
Deep ProcessingThreaded,sockets,end cap,painting,powder coated, oiled, punching,shrink,woven bag, stamping,embossing ect.
ApplicationsSteel Structure,Scaffolding,Fence,Conduit,Greenhouse,Decorative pipe, Post, Roofing





Galvanized round pipe specifications:


Outer DiameterWall ThicknessLength
Inchmmmmmeter
1/2"21.3mm0.6mm-3.0mm0.3m-12m
3/4"26.9mm0.6mm-3.0mm0.3m-12m
1"33.4mm1.0mm-3.0mm0.3m-12m
1-1/4"42.3mm1.0mm-4.0mm0.3m-12m
1-1/2"48.3mm1.0mm-4.0mm0.3m-12m
2"60.3mm1.5mm-4.0mm0.3m-12m
2-1/2"76.1mm1.5mm-4.0mm0.3m-12m
3"88.9mm1.5mm-9.5mm0.3m-12m
4"114.3mm2.0mm-9.5mm0.3m-12m
5"141.3mm3.0mm-9.5mm0.3m-12m
6"168.3mm3.0mm-12.0mm1.0m-12m
8"219.1mm3.2mm-12.0mm1.0m-12m
10"273mm3.2mm-12.0mm1.0m-12m
12"323.8mm6.0mm-15.0mm1.0m-12m
14"355.6mm8.0mm-15.0mm1.0m-12m
16"406.4mm8.0mm-20.0mm1.0m-12m


FREIGHT LOGISTICS

Tisco Hongcheng Tech Co.,Ltd

  • Galvanized pipe

Company Profile

Tisco Hongcheng Tech Co.,Ltd


Company Profile

Tisco Hongcheng Tech Co.BLtd was founded in 2018 year, headquartered in shandong province,with tianjin, qingdao,wuxi ,shanghai branch. It is a professional one-stop worldwide steel supplier, we specialized in providing customized solution to customer client across Asia,European,middle east,south America,Africa region etc.we are positioned as a trusted and reliable global partner.

Our core products included steel coil,steel pipe, steel sheet, PPGI,PPGL,steel profile, steel fitting, alloy series,lead series, copper aluminum series etc.

We has passed ISO9001,ISO14001,ISO45001 and CE certified facilities ,with annual output of 100million tons,efficient shipping and warehouse network ensuring timely delivery Our team offer end-end support, from prouduct selection to after sales service. Let's Build the future together. Welcome to china to visit us !to visit us!

We will adhere to the "reputation first, customer first" principle, always put the interests of customers in the first place, dedicated to provide each customer with the best products and the best service.

Choosing us means you choose better service and quality products. Welcome domestic and foreign customers to negotiate business.

Company Profile

Tisco Hongcheng Tech Co.,Ltd


Company Profile

Tisco Hongcheng Tech Co.,Ltd


Related products

Tisco Hongcheng Tech Co.,Ltd

FAQ

Tisco Hongcheng Tech Co.,Ltd

Q: ARE YOU A MANUFACTURER OR A TRADING COMPANY?
A: Manufacturer.



Q: WHAT'S THE PRODUCTION PERIOD?
A: For standard equipment, it takes 30 working days. If it's customized product, it takes 45-60 days.



Q: WHAT'S THE PAYMENT TERM?
A: 1. 30% T/T after contract confirmation, 70% T/T before delivery.2. 100% irrevocable L/C at sight.



Q: WHAT'S THE MINIMUM ORDER QUANTITY?
A: 1 unit.



Q: WHAT'S THE WARRANTY PERIOD?
A: 12 months.



Q: IS OEM SERVICE AVAILABLE?
A: Yes, it's acceptable.
